Robotic Disc Filter Cleaning System

Automated Robotic Cleaning for Metallic Disc Filters

Purofiltec's Robotic Disc Filter Cleaning System is an advanced automated solution designed for cleaning metallic disc filters used in polymer melt filtration. The system combines robotic handling, high-pressure hydro-air backwash cleaning, and external pressurized water jet cleaning to deliver consistent, repeatable, and completely unattended cleaning.

View Specifications Send Technical Enquiry
Fully Robotic Operation
Automatic Pick & Place
Industry 4.0 Ready
Robotic Disc Filter Cleaning System
Robotic Filter Cleaning
Robotic Disc Filter Cleaning System
Automated Robotic Disc Filter Cleaning
PRODUCT OVERVIEW

Fully Automated Disc Filter Cleaning

Purofiltec's Robotic Disc Filter Cleaning System is an advanced automated solution designed for cleaning metallic disc filters used in polymer melt filtration. The system combines robotic handling, high-pressure hydro-air backwash cleaning, and external pressurized water jet cleaning to deliver consistent, repeatable, and completely unattended cleaning.

Unlike conventional cleaning methods, the system automatically picks individual disc filters from a loading tray, performs a complete internal and external cleaning cycle, and places the cleaned disc into the unloading tray without any manual intervention.

Designed for modern polymer processing plants, the robotic system improves cleaning quality, reduces labor requirements, minimizes handling damage, and increases overall maintenance efficiency.

WORKING PRINCIPLE

Fully Automated Disc Filter Cleaning Process

The complete cleaning process is fully automated.

01
STEP 01

Batch Loading

Operator loads a stack of 25 or 50 contaminated disc filters into the loading tray.

02
STEP 02

Automatic Disc Picking

Industrial robotic arm automatically picks one disc.

03
STEP 03

Disc Transfer

Disc is transferred to the cleaning station.

04
STEP 04

Hydro-Air Backwash

High-pressure Hydro-Air Backwash cleans the filter from inside to outside, removing trapped polymer contaminants.

05
STEP 05

External Water Jet Cleaning

External pressurized water jets clean both filter surfaces.

06
STEP 06

Automatic Unloading

Robot transfers the cleaned disc to the unloading tray.

07
STEP 07

Automatic Cycle Repetition

The cycle repeats automatically until the complete batch is cleaned.

Fully Automated Operation No manual handling is required during the cleaning cycle.
KEY BENEFITS

Benefits

Eliminates Manual Cleaning

Reduces Labor Costs

Consistent Cleaning Performance

Increased Productivity

Reduced Operator Exposure

ENGINEERED PERFORMANCE

Key Features

The robotic cleaning system combines automated disc handling, hydro-air backwash, external high-pressure water jet cleaning, and programmable robotic operation to provide consistent and repeatable disc filter cleaning.

Fully Robotic Operation

Automatic Disc Loading & Unloading

Hydro-Air Backwash Cleaning

External High-Pressure Water Jet Cleaning

Individual Disc Cleaning

Human-Free Operation

PLC & HMI Control

Industrial Robot Integration

Adjustable Cleaning Parameters

Repeatable Cleaning Quality

Industry 4.0 Ready

TECHNICAL DATA

Technical Specifications

The Robotic Disc Filter Cleaning System is designed for fully automated batch cleaning of metallic disc filters using robotic handling, Hydro-Air Backwash, and external high-pressure water jet cleaning.

25 / 50 Discs per Tray BATCH CAPACITY
The complete cleaning cycle is programmable, with automatic pick-and-place handling and cleaning operations performed without manual intervention.
PARAMETER SPECIFICATION
Cleaning Object
Metallic Disc Filters
Batch Capacity
25 or 50 Discs per tray
Cleaning Method
Hydro-Air Backwash + High-Pressure Water Jets
Internal Cleaning
Reverse Flow Hydro-Air
External Cleaning
Pressurized Water Jets
Handling System
Industrial Robotic Arm
Operation
Fully Automatic
Control System
PLC with Touch Screen HMI
Disc Transfer
Automatic Pick & Place
Cleaning Cycle
Fully Programmable
Human Intervention
Loading & Unloading Only
FAQ

Frequently Asked Questions

Technical answers to common questions about Robotic Disc Filter Cleaning Systems.

The operator places a stack of 25 or 50 dirty disc filters in the loading tray. The robotic arm automatically picks each disc, performs hydro-air backwash cleaning followed by external high-pressure water jet cleaning, and places the cleaned disc into the output tray.

No. Once the batch is loaded and the cleaning program is started, the complete cleaning process is fully automatic. Manual intervention is only required for loading dirty discs and removing the cleaned batch.

The robotic system provides repeatable cleaning quality, minimizes labor requirements, reduces handling damage, improves safety, shortens maintenance time, and delivers consistent cleaning performance across every disc.

The loading tray is designed to accommodate a stack of 25 or 50 contaminated metallic disc filters per batch.

Yes. The cleaning cycle combines internal hydro-air backwash with external pressurized water jets to clean the filter surfaces.
